彩涂卷组合房间具有什么特点

彩涂卷组合房间具有什么特点

彩涂卷组合房具有以下特点:
1、 彩涂卷组合房抗震7级,抗风8级;
2.二层设计能承受150kg/m2的动荷载;
3、 彩涂卷组合房使用年限在十年以上。
4、本产品防火等级为甲级。
彩涂卷组合房材说明如下:EPS保温夹芯板、聚乙烯醇彩钢夹芯板、岩棉彩钢夹芯板、玻璃棉夹芯彩钢板、塑料钢板。

163303294246
1) EPS隔热夹芯板:是以彩涂钢板为表面材料,以自熄性聚乙烯为芯材,在连续成型机中加热压制而成的热固化胶粘剂和压力复合材料制成的超轻型建筑板。具有自发光(混凝土屋顶的1/20-1/30)和隔热(导热系数为0.034w/mk)。施工速度快(无湿作业,无二次装修,是集置换、保温、防水、装饰于一体的新型围护材料)
2) 彩钢夹芯板:乙级防火、防腐、防锈、耐候
3) 岩棉彩钢夹芯板:具有甲级防火、隔热、隔音、防火等性能
4) 玻璃棉彩钢夹芯板:甲级防火,与岩棉板相比,板材简单,可与屋面配套使用
5) 塑钢板:外形美观,使用寿命长,防火等级为甲级
活动室的类型和技术
类型:轻钢组合房、彩钢板房、高雅活动房、集装箱房、钢结构厂房、彩钢板棚等。
技术二:单坡式、双坡式、四坡式三种,层数1-3层。
区域会计理念
1.板房面积按外墙边缘宽度按层数计算比较。
2.室外楼梯、走道按自然层投影面积之和计算。3.雨棚按水平投影面积的一半计算。
4.板伸出墙外不考虑施工面积。
5.总面积=(1)+(2)+(3)。
6.标准层有两个楼梯。你可以找一面墙。当您将楼梯增加或减少4.5m2时,可以根据此数字添加或减少楼梯。
7.除注明外,工程量清单计算按上述计算公式进行调整结算。

The light steel combined room has the following characteristics:

1. the color steel plate movable room is of seismic grade 7 and wind resistance Grade 8;
2. the design of the second floor can bear the dynamic load of 150kg/ m2;
3. the service life of the movable board room is more than ten years.
4. the fire protection grade of this product is Grade A.
The board of the movable room is stated as follows: EPS insulated sandwich board, poly * * Vinyl Color steel sandwich board, rock wool color steel sandwich board, glass wool sandwich color steel plate and plastic steel plate.
1) EPS heat insulation sandwich board: it is a super light building plate which is made of color coated steel plate as surface material, self extinguishing * * ene as core material, and is made of heat curing adhesive and pressure composite by heating and pressing in the continuous forming machine. It has self lightening (1 / 20-1 / 30 of the concrete roof), and heat insulation (its thermal conductivity value is 0.034w/mk). The construction rate is fast (the features of no wet operation and no secondary decoration are a new type of envelope material integrating the replacement, heat preservation, waterproof and decoration)
2) Polychromatic steel sandwich board: Class B fire protection, corrosion prevention, rust prevention and weather resistance
3) Rock wool color steel sandwich board: class a fire protection, heat insulation, sound insulation, fire protection and other properties
4) Glass wool color steel sandwich board: class a fire protection, compared with rock wool board, the plate is simple and can be used with roof
5) Plastic steel plate: elegant appearance, long service life, class a fire protection
Types and techniques of the activity room
Types: light steel combined room, color steel plate room, elegant activity room, container room, steel structure factory room, color steel shed, etc.
Technology two: there are three examples of single slope type, double slope type and four slope type, with the number of layers being 1-3.
Area acounting idea
1. The area of slab room is calculated and compared by the width of the outer wall edge by the number of layers.
2. Outdoor stairs and walkways are calculated according to the sum of projected area of natural layer. 3. The canopy is calculated by half of the horizontal projection area.
4. No account shall be given to the area of construction for the slab extending out of the wall.
5. The total area = (1) + (2) + (3).
6. There are two stairs on the standard floor. You can get one of the walls. When you increase or decrease the stairs by 4.5m2, you can add or decrease the stairs according to this number.
7. Except as noted, the bill of quantities calculation shall be adjusted and settled according to the above calculation formula.
