彩钢板搭建时，侧向和端部应该如何搭接
天物彩板集团专注彩涂卷行业17年——更多彩钢板侧向和端部应该如何搭接_顺义彩钢板品牌排行榜请拨打网站上方电话咨询
目前，彩钢板应用广泛，彩钢板的施工也充满了很多知识。由于彩钢板与传统的建筑材料有很大的不同，它也不同于一般的模型。
在这里，让我们谈谈彩色钢板的侧面和末端的构造。
安装每一块彩钢板时，其边缘搭接应准确放置在前一块彩钢板上，并与前一块彩钢板夹紧，直至彩钢板两端固定。一种简单有效的方法是用夹钳夹住重叠的钢板。彩钢板纵向就位时，其端部特别是上端需要钳子夹住搭接部分，以保证彩钢板一端就位，一端搭接也在正确位置，从而固定彩钢板。在固定过程中，钳子应始终纵向夹住彩钢板。在安装下一块彩钢板之前，每一块彩钢板必须完全固定。固定必须从钢板的中心开始，然后延伸到两侧，最后固定钢板的搭接边。对于端部搭接，由于屋面和墙体型钢板是连续加工制成的，因此可根据运输条件限制的长度供应钢板。一般不需要搭接，彩钢板长度足以满足屋面铺设的需要。考虑到现场处理和运输，如有必要，可使用两块较短的钢板通过端部搭接覆盖整个长度。彩色钢板每根立柱的搭接顺序为自下而上，然后放下一根立柱。对于采用贯穿固定法的屋面和墙体，钢板的端搭接应定位在支架上。坡度为1/12（50）~1/4（150）的屋面，钢板端部搭接长度至少为200mm；当坡度超过1/4（150）时，搭接长度至少为150mm，彩钢板端部搭接部分的中点应在支架的中心。
这样，我们制造的彩钢板更加坚固可靠。使用彩色钢板也会更安全。
At present, color steel plate is widely used, and the construction of color steel plate is also full of a lot of knowledge. Because color steel plate is very different from traditional building materials, it is also different from the general model.
Here, let's talk about the construction of the side and end of the color steel plate.
When installing each color steel plate, its edge lap shall be accurately placed on the previous color steel plate and clamped with the previous color steel plate
until both ends of the color steel plate are fixed. A simple and effective method is to clamp the overlapped steel plates with a pair of clamping pliers. When the color steel plate is in place longitudinally, its end, especially the upper end, needs pliers
to clamp the lap part, so as to ensure that one end of the color steel plate is in place and the lap of one end is also in the correct position, so as to fix the color steel plate. In the process of fixing, the pliers should always clamp the color steel
plate longitudinally. Before installing the next color steel plate, each color steel plate must be completely fixed. The fixing must start at the center of the steel plate, then extend to both sides, and finally fix the lap edge of the steel plate. For
end lap, because the roof and wall profile plates are made by continuous processing, the steel plate can be supplied according to the length limited by transportation conditions. Generally, lap is not required, and the length of color steel plate is enough
to meet the needs of roof laying. In consideration of on-site treatment and transportation, if necessary, two shorter steel plates can be used to cover the whole length through end lap. The lap sequence of each column of color steel plates is from bottom
to top, and then put down one column. For the roof and wall with penetration fixing method, the end lap of steel plate shall be positioned on the support. For the roof with a slope of 1 / 12 (50) ~ 1 / 4 (150), the overlapping length of the steel plate
end shall be at least 200mm; when the slope exceeds 1 / 4 (150), the overlapping length shall be at least 150mm, and the midpoint of the overlapping part of the color steel plate end shall be in the center of the support.
In this way, the color
steel plate built by us is more firm and reliable. The use of color steel plate will also be safer.
